Description
Elevate your operations with the DJI Matrice 4TD, a high performance drone built for all weather inspections, public safety, and mission critical tasks. By combining advanced thermal imaging, high resolution visual sensors, and a long range laser rangefinder within a single compact payload, the M4TD provides precise, real time aerial intelligence where it matters most.
Overview and Key Features
Built to perform in extreme conditions, the Matrice 4TD features an IP55 weather resistance rating and up to 54 minutes of flight time. Fully compatible with DJI Dock 3 and DJI FlightHub 2, this platform enables seamless autonomous deployment, remote site monitoring, and beyond visual line of sight operations.
-
Multi Sensor Payload: Includes a 48MP zoom camera, wide angle RGB lens, high resolution thermal sensor, and an 1800m laser rangefinder.
-
360 Degree Obstacle Sensing: Equipped with a rotating LiDAR module and millimeter wave radar for complete situational awareness.
-
Low Light Precision: Near infrared auxiliary lighting ensures clear visibility during night or low contrast operations.
-
Reliable Connectivity: Features an onboard relay module and 4G connectivity to maintain stable transmission across challenging terrain.
Technical Specifications
| Specification | Details |
| Max Flight Time | Up to 54 minutes |
| Ingress Protection | IP55 rated (dust and water splash resistant) |
| Camera Suite | Triple sensor: Wide RGB, Telephoto RGB, 640×512 Thermal (IR) |
| Distance Measurement | Integrated Laser Rangefinder (up to 1800 m range) |
| Obstacle Avoidance | 360° coverage via Rotating LiDAR and Millimeter Wave Radar |
| Max Flight Speed | ~23 m/s (approx 82.8 km/h) |
| Operating Temperature | -20°C to 50°C |
| Transmission & Software | O3 Enterprise (up to 15 km), DJI FlightHub 2, DJI Dock 3 compatible |
| Power & Redundancy | Dual TB65 battery system, dual IMU, dual compass, RTK support |
Gimbal Specifications
Wide-Angle Camera
1/1.3-inch CMOS
48MP Effective Pixels
f/1.7
24mm Format Equivalent
Medium Tele Camera
1/1.3-inch CMOS
48MP Effective Pixels
f/2.8
70mm Format Equivalent
Medium Tele Camera
1/1.3-inch CMOS
48MP Effective Pixels
f/2.8
70mm Format Equivalent
Tele Camera
1/1.5-inch CMOS
48MP Effective Pixels
f/2.8
168mm Format Equivalent
Tele Camera
1/1.5-inch CMOS
48MP Effective Pixels
f/2.8
168mm Format Equivalent
Laser Range Finder
Measurement Range: 1800 m (1 Hz);
Oblique Incidence Range (1: 5 Oblique Distance): 600 m (1 Hz)
Blind Zone: 1 m
Range Accuracy (m): ± (0.2 + 0.0015 × D)
Laser Range Finder
Measurement Range: 1800 m (1 Hz);
Oblique Incidence Range (1: 5 Oblique Distance): 600 m (1 Hz)
Blind Zone: 1 m
Range Accuracy (m): ± (0.2 + 0.0015 × D)
NIR Auxiliary Light
6° FOV, 100m Illumination Distance
Infrared Thermal Camera
640×512 Resolution
f/1.0
53mm Format Equivalent
Uncooled VOx Microbolometer
Supports UHR Infrared Image mode
Warranty
24 Months Warranty
Designed for professionals who demand total reliability in any weather condition, the DJI Matrice 4TD gives teams the power to act faster, make safer decisions, and cover more ground efficiently.
